HS-F106 Full-Automatic Handbag Die Cutting Machine

1) Maximum die cutting and mark pressing force: 300KN 2) Specification of die cutting and mark pressing: 1100x700mm 3) Width of dice: 1100mm 4) Total power (appropriate): 5KW 5) Power supply: AC 380V/50HZ, AC 220V/50HZ 6) Outline dimensions: 7200x2700x2100mmUsage and characteristics:1. The production line is applicable for synchronously carrying out die cutting, mark pressing, bronzing and dice cutting of matted film combined pearlized film, matted film laminating paper, OPP printing laminating paper and OPP combined pearlized film etc. rolled materials in printing, packaging and bag making etc. industries. 2. The production line integrates die cutting, mark pressing, bronzing and dice cutting etc. four working procedures into one. The four working procedures can be completed at the same time period, which has greatly enhanced production efficiency. Only one worker is required for the whole production line, which has greatly reduced production cost. 3. The main machine adopts hydraulic precise die cutting mark pressing machine to carry out mark pressing and die cutting with good mark pressing effect and high accuracy, and the power can be almost 2/3 saved. 4. The automatic photoelectric deviation correction feeding and photoelectric tracking compensation material pulling device is adopted, which guarantees accurate mark pressing and dice cutting position and reduces waste of leftover materials. 5. The whole production line adopts gantry type enclosed structure, safe and reliable with beautiful appearance. 6. The production line adopts central control desk for centralized control. Each working procedure can work separately and also work simultaneously with others.
